High Productivity
720boxes/h
Fast Size Change
Adjustments by handwheels that guarantee precision and repeatability.
Cycle type selection
Continuous cycle or lots.
|
Model |
CES4035M |
|
Suitable Case |
L200-500mm / W150- 400mm H100-350mm H+1/2W<550mm |
|
Height of table |
Min.H650mm Max.H700mm |
|
Work speed |
6-15carton/min. |
|
Power |
Single phase, 110V or 220V/ 50/60HZ , 300W |
|
Air Source |
＞500L/min、 0.4~0.8 Mpa |
|
Opp tape |
W50mm or W60mm or W75mm |
|
Machine Weight |
NW-400KG GW-450kg |
|
|
Carton Output Way: From Right to Left |
